Brand

Dahua

Product Type

Bullet Camera

Series

Entry

Product Code

DH-IPC-HDBW1230RP-ZS-S4

Camera

Image Sensor

1/2.7" 2Megapixel progressive CMOS

Effective Pixels

1920 (H) × 1080 (V)

Rom

16 MB

Ram

64 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.008 Lux F1.7

IR Distance

40 m (131.2 ft)

IR On/Off Control

Auto/Manual

IR Leds Number

2

Pan/Tilt/Rotation Range

Pan: 0°–355° Tilt: 0°–75° Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.8 mm–12 mm

Max. Aperture

F1.7

Field Of View

Pan: 106°–33° Tilt: 56°–19° Diagonal: 127°–38°"

IRIS Type

Fixed

Close Focus Distance

0.8 m (2.6 ft)

Dori Distance

Lens

Detect

Observe

Recognize

Identify

W

44.0 M (144.4 Ft)

17.6 m (57.7 ft)

8.8 m (28.9 ft)

4.4 m (14.4 ft)

T

153.1 M (502.3 Ft)

61.2 m (200.8 ft)

30.6 m (100.4 ft)

15.3 m (50.2 ft)

Smart Event

General Ivs Analytics

Tripwire; intrusion

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG

Smart Codec

Yes

Video Frame Rate

Main Stream: 1920 × 1080 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps)

Stream Capability
